Hensel, KVPC9112 Box, Circuit Breaker 12 Modules, c/w Terminals IP65, KV Small-Type Distribution Boards, Size: 1x12x18mm, Finish: Grey
Share
Categories : Circuit Breaker Box ,
Brand : HENSEL
Share
KVPC9112, HENSEL Circuit Breaker 12 Modules, c/w Terminals IP65
Hensel, KVPC9112 Box, Circuit Breaker 12 Modules, c/w Terminals IP65, KV Small-Type Distribution Boards, Size: 1x12x18mm, Finish: Grey
Feature:
- 12 modules: 1 x 12 x 18 mm
- 1-row
- cable entry via integrated elastic membranes
- per PE/N number x cross section 3 x 25 mm², 12 x 4 mm² Cu, FIXCONNECT®terminal technology, for terminal technology refer to technical data
- N separable, for up to 2 different potentials
- for indoor (normal environment and/or protected outdoor) and outdoor installation (harsh environment and/or outdoor)
- for the installation of DIN rail equipment, top hat profile 35 mm
- with transparent door
- for door locking device and sealing device refer to accessories
- with cable entry cover
- with blanking strips for unused DIN rail openings
- lateral enclosure connections can be managed by drilling
- Degree of protection: IP 65
- Colour: grey, RAL 703
