KV9104, HENSEL Circuit breaker boxes 3-54 modules IP65

Name: KV9104, HENSEL Circuit breaker boxes 3-54 modules IP65
Brand: HENSEL
SKU: KV9104
Availability: InStock

Attribute:

Circuit Breaker 4.5 Modules, Integrated Elastic Membranes IP65, KV Small-Type Distribution Boards, Size: 1x4.5x18mm, Finish: Grey

Categories : Circuit Breaker Box ,

Brand : HENSEL

KV9104, HENSEL Circuit breaker boxes 3-54 modules IP65

Circuit Breaker 4.5 Modules, Integrated Elastic Membranes IP65, KV Small-Type Distribution Boards, Size: 1x4.5x18mm, Finish: Grey

Feature:
- 4.5 modules: 1 x 4.5 x 18 mm
- 1-row
- per PE/N number x cross section 2 x 25 mm², 4 x 4 mm² Cu, FIXCONNECT®terminal technology, for terminal technology refer to technical data
- for the installation of DIN rail equipment, top hat profile 35 mm
- with transparent lid, sealable
- locking device for hinged lid and sealing facility see accessories
- with cable entry cover
- protective cover can be cut out
- cable entry via integrated elastic membranes
- Degree of protection: IP 65
- Colour: grey, RAL 7035
