KV1503, HENSEL Circuit breaker boxes 3-54 modules

Name: KV1503, HENSEL Circuit breaker boxes 3-54 modules
Brand: HENSEL
SKU: KV1503
Availability: InStock

Attribute:

Hensel KV1503 : Box, Circuit Breaker 3 Modules IP54 1x3x18mm Grey, Size: 1x3x18mm

Categories : Circuit Breaker Box ,

Brand : HENSEL

KV1503, HENSEL Circuit breaker boxes 3-54 modules

Hensel KV1503 : Box, Circuit Breaker 3 Modules IP54 1x3x18mm Grey,Hensel, KV1503 Box, Circuit Breaker 3 Modules IP54, KV Small-Type Distribution Boards

Feature:
-3 modules: 1 x 3 x 18 mm
-1-row
-per PE/N number x cross section 1 x 25 mm², 4 x 4 mm² Cu, FIXCONNECT®terminal technology, for terminaltechnology refer to technical data
-for the installation of DIN rail equipment, top hat profile 35 mm
-with transparent lid, sealable
-locking device for hinged lid and sealing facility see accessories
-with cable entry cover
-protective cover can be cut out
-cable entry via integrated elastic membranes
-degree of protection: IP 54
-Color: grey, RAL 7035
