Cable junction boxes ”Weatherproof“ for outdoor installation, Size: 130x130x77mm.,1.5-4 mm², Cu 3~, terminal with 2 clamping units per pole, grey, RAL 7035
Share
Categories : Cable Junction Boxes ,
Brand : HENSEL
Share
KF0604G, HENSEL Cable junction box
Cable junction boxes ”Weatherproof“ for outdoor installation, Size: 130x130x77mm.,1.5-4 mm², Cu 3~, terminal with 2 clamping units per pole, grey, RAL 7035
Feature:
- 1.5-4 mm², Cu 3~
- terminal with 2 clamping units per pole
- 5-pole per pole 8 x 1,5 mm² sol / f, 6 x 2,5 mm² sol / f, 4 x 4 mm² sol / f, 2 x 6 mm² sol / f
- with one cable entry M 25 from the rear side
- cable entries via knockouts, order ASS separately (see cable entry systems LES)
- "weatherproof" resistant to weather influences (UV due to solar radiation, protected against rainwater, temperature resistant, impact resistant, etc.)
- saltwater-proof
- "offshore applications"
- lid fasteners sealable without accessories
- retaining strap and external brackets for wall fixing included
- Color: grey, RAL 7035
