KV 7109, HENSEL Circuit breaker boxes 9 modules IP65
Attribute:
Hensel, Circuit Breaker 9 Modules, 1-row, colour: grey, RAL 7035, KV Small-Size: 1x9x18mm.
Share
Categories : Circuit Breaker Box ,
Brand : HENSEL
Share
KV 7109, HENSEL Circuit breaker boxes 9 modules IP65
Hensel, KV7109 Box, Circuit Breaker 9 Modules, Metric Knockouts IP65, KV Small-Type Distribution Boards, Circuit Breaker Boxes. Size: 1x9x18mm, Finish: Grey
Feature:
- 9 modules: 1 x 9 x 18 mm
- 1-row
- knockouts: top and bottom walls 4x M20/25 and 1x M25/32 each
- per PE/N number x cross section 2 x 25 mm², 8 x 4 mm² Cu, FIXCONNECT® terminal technology, for terminal technology refer to technical data
- for the installation of DIN rail equipment up to 63 A, top hat profile 35 mm
- with transparent lid, sealable
- locking device for hinged lid and sealing facility see accessories
- with cable entry cover
- protective cover can be cut out
- degree of protection: IP 65
- colour: grey, RAL 7035
