KV 9350, HENSEL Circuit breaker boxes 36 modules IP65
Attribute:
Hensel, Circuit Breaker 36 Modules, Elastic Membranes IP54, KV Small-Size: 2x18x18 mm.
Share
Categories : Circuit Breaker Box ,
Brand : HENSEL
Share
KV 9350, HENSEL Circuit breaker boxes 36 modules IP65
Hensel, KV9350 Box, Circuit Breaker Extra 36 Mod, Integrated Elastic Membranes IP65, KV Small-Type Distribution Boards, Circuit Breaker Boxes. Size: 2x18x18mm, Finish: Grey
Feature:
- 36 modules: 2 x 18 x 18 mm
- without PE and N terminal
- 2-row
- order PE/N terminals separately
- for the installation of DIN rail equipment up to 63 A, top hat profile 35 mm
- with additional space for electrical devices not to be manually actuated
- with 1 DIN rail, 381 mm wide, for DIN rail equipment and terminal blocks with max. mounting depth 72 mm
- with transparent door
- for door locking device and sealing device refer to accessories
- with cable entry cover
- with blanking strips for unused DIN rail openings
- cable entry via integrated elastic membranes
- degree of protection: IP 65
- colour: grey, RAL 7035
