3P+E 32A 380-415V 50/60HZ - RED - 6H - SCREW WIRING, straight mobile and 10° flush-mounting
Share
Categories : Power Plug ,
Brand : GEWISS
Share
| Part Number | GW62041H |
| Colour | RED |
| IP degree | IP66/67/68/69 |
| Mechanical resistance | IK09 |
| Rated voltage | 380-415 V |
| Frequency | 50/60 Hz |
| Cable clamp tightening capacity | 9.2-19.9 mm |
| Type of wiring | With screw |
| Electrocod | 2211 |
| Total number of operations | > 2000 |
| Breaking capacity at 1.1 Un | 40 A |
| Thermo-pressure with ball | 125 °C (active parts) - 80 °C (passive parts) |
| Rated current (A) | 32 |
| No. of poles | 3P+E |
| Reference h | 6 |
| Type | Straight connector |
| Terminal tightening capacity | 2.5-6mm² flexible cables - 2.5-10mm² rigid cables |
| Operating temperature | -25 +55 °C |
| Type of material | Halogen-free in compliance with EN 60754-2 |
| Glow wire test | 850 °C (active parts) - 650 °C (passive parts) |
| Permissible overload | 42 A |
| Insulation resistance | > 10 M |
