WITH BOTTOM - WITH FUSE-HOLDER BASE - 2P+E 16A 200-250V-50/60HZ 6H - IP66
Share
Categories : Power Plug ,
Brand : GEWISS
Share
| Part Number | GW66954 |
| Type | Vertical |
| Type of fuse | Ø 10.3x38 mm |
| Impact resistance at -20 °C | 20 J |
| No. of poles | 2P+E |
| Frequency | 50/60 Hz |
| Protection | Fuse-holder base (CBF) |
| Electrocod | 2222 |
| Colour | Blue |
| Reference h | 6 |
| Type of use | Heavy duty |
| Thermo-pressure with ball | 80 °C |
| IP degree | IP66 |
| Mechanical resistance | > IK10 |
| Operating temperature | -25 +40 °C |
| With back-mounting box | Yes |
| Glow wire test | 850 °C |
| Rated current (A) | 16 |
| Rated voltage | 200-250 V |
