GW66054N VERTICAL FIXED INTERLOCKED SOCKET OUTLET

Name: GW66054N VERTICAL FIXED INTERLOCKED SOCKET OUTLET
Brand: GEWISS
SKU: GW66054N
Availability: InStock

Attribute:

AUTOMATIKA - MT 6KA CURVE C - WITH BOTTOM - 2P+E 16A 230V 6H - IP67 System of industrial socket-outlets for power distribution in the industrial.

Categories : Power Plug ,

Brand : GEWISS

GW66054N VERTICAL FIXED INTERLOCKED SOCKET OUTLET

System of industrial socket-outlets for power distribution in the industrial and commercial sector, equipped with locking device, enabling the most varied professional requirements of installers and panel builder to be met. The IB range is composed of 4 product lines: IP67 standard vertical socket-outlets, IP66 vertical socket-outlets for heavy duty applications, IP44 horizontal socket-outlets and IP44 and IP55 compact socket-outlets.

Part Number	GW66054N
Colour	Blue
IP degree	IP67
Mechanical resistance	IK08
Rated voltage	200-250 V
Frequency	50/60 Hz
Protection	MCB
Electrocod	2222
Thermo-pressure with ball	125 °C (IB socket) - 80 °C (bottom)
Rated current (A)	16
No. of poles	2P+E
Reference h	6
Type	Vertical
Operating temperature	-25 +40 °C
With back-mounting box	Yes
Glow wire test	850 °C (IB socket) - 650 °C (bottom)
Circuit breaker	MT 6 kA C Characteristic
