2P+E 125A 200-250V 50/60HZ - BLUE - 6H - straight mobile and 10° flush-mounting, MANTLE TERMINAL.
Share
Categories : Power Plug ,
Brand : GEWISS
Share
| Part Number | GW62665H |
| Colour | Blue |
| IP degree | IP66/IP67/IP68/IP69 |
| Mechanical resistance | IK09 |
| Rated voltage | 200 - 250 V |
| Frequency | 50/60 Hz |
| Cable clamp tightening capacity | 24.7-38.5 mm |
| Type of wiring | Mantle terminal |
| Electrocod | 2211 |
| Total number of operations | > 500 |
| Breaking capacity at 1.1 Un | 156 A |
| Thermo-pressure with ball | 125 °C (active parts) - 80 °C (passive parts) |
| Rated current (A) | 125 |
| No. of poles | 2P+E |
| Reference h | 6 |
| Type | Straight connector |
| Terminal tightening capacity | 16-50mm² flexible cables - 25-70mm² rigid cables |
| Operating temperature | -25 +55 °C |
| Type of material | Halogen-free in compliance with EN 60754-2 |
| Glow wire test | 850 °C (active parts) - 650 °C (passive parts) |
| Insulation resistance | > 10 MΩ |
