3P+E - 63A - 380-415V 50/60HZ - RED - 6H - straight mobile and 10° flush-mounting, MANTLE TERMINAL.
Share
Categories : Power Plug ,
Brand : GEWISS
Share
| Part Number | GW61020H |
| Colour | Red |
| IP degree | IP44/IP54 |
| Mechanical resistance | IK09 |
| Rated voltage | 380 - 415 V |
| Frequency | 50/60 Hz |
| Cable clamp tightening capacity | 17.9-37 mm |
| Type of wiring | Mantle terminal |
| Electrocod | 2210 |
| Total number of operations | > 2000 |
| Breaking capacity at 1.1 Un | 79 A |
| Thermo-pressure with ball | 125 °C (active parts) - 80 °C (passive parts) |
| Rated current (A) | 63 |
| No. of poles | 3P+E |
| Reference h | 6 |
| Type | Straight plug |
| Terminal tightening capacity | 6-16mm² flexible cables - 6-25mm² rigid cables |
| Operating temperature | -25 +55 °C |
| Type of material | Halogen-free in compliance with EN 60754-2 |
| Glow wire test | 850 °C (active parts) - 650 °C (passive parts) |
| Insulation resistance | > 10 M |
