GW62231FH 10° ANGLED FLUSH-MOUNTING SOCKET-OUTLET HP - IP66/IP67
Attribute:
3P+E 16A 380-415V 50/60HZ - RED - 6H - Plugs and socket-outlets IEC 309 Standard, FAST WIRING.
Share
Categories : Power Plug ,
Brand : GEWISS
Share
| Part Number | GW62231FH |
| Colour | Red |
| IP degree | IP66/IP67 |
| Mechanical resistance | IK09 |
| Rated voltage | 380-415 V |
| Frequency | 50/60 Hz |
| Cable clamp tightening capacity | 7.5-13.8 mm |
| Type of wiring | Quick, with spring T |
| Electrocod | 2210 |
| Total number of operations | > 5000 |
| Breaking capacity at 1.1 Un | 20 A |
| Thermo-pressure with ball | 125 °C (active parts) - 80 °C (passive parts) |
| Rated current (A) | 16 |
| No. of poles | 3P+E |
| Reference h | 6 |
| Flange dimensions (mm) | 85x75 |
| Type | 10° angled flush-mounting socket-outlet |
| Terminal tightening capacity | 1-2.5mm² flexible cables - 1.5-4mm² rigid cables |
| Operating temperature | -25 +55 °C |
| Type of material | Halogen-free in compliance with EN 60754-2 |
| Glow wire test | 850 °C (active parts) - 650 °C (passive parts) |
| Permissible overload | 22 A |
| Insulation resistance | > 10 MΩ |
