GW60030FH STRAIGHT PLUG HP - IP66/IP67/IP68/IP69
Attribute:
The IEC 309 HP system comprises plugs and socket-outlets from 16 to 125A in two different versions – FAST WIRING
Share
Categories : Power Plug ,
Brand : GEWISS
Share
| Part Number | GW60030FH |
| Colour | Red |
| IP degree | IP66/IP67/IP68/IP69 |
| Mechanical resistance | IK09 |
| Rated voltage | 380-415 V |
| Frequency | 50/60 Hz |
| Cable clamp tightening capacity | 7.5-13.8 mm |
| Type of wiring | Quick, with spring |
| Electrocod | 2230 |
| Total number of operations | > 5000 |
| Breaking capacity at 1.1 Un | 20 A |
| Thermo-pressure with ball | 125 °C (active parts) - 80 °C (passive parts) |
| Rated current (A) | 16 |
| No. of poles | 3P+E |
| Reference h | 6 |
| Type | Straight plug |
| Terminal tightening capacity | 1-2.5mm² flexible cables - 1.5-4mm² rigid cables |
| Operating temperature | -25 +55 °C |
| Type of material | Halogen-free in compliance with EN 60754-2 |
| Glow wire test | 850 °C (active parts) - 650 °C (passive parts) |
| Permissible overload | 22 A |
| Insulation resistance | > 10 MΩ |
