KV 9354, HENSEL Circuit breaker boxes 54 modules
Attribute:
Hensel Box, KV Small-type Distribution Boards up to 63 A KV Circuit breaker boxes 54 modules, c/w Terminals IP65
Share
Categories : Circuit Breaker Box ,
Brand : HENSEL
Share
KV9354, HENSEL Circuit breaker boxes with metric knockouts
Hensel Box, KV9354 Box, Circuit Breaker 54 Modules, c/w Terminals IP65, KV Small-Type Distribution Boards, Circuit Breaker Boxes. Size: 3x18x18mm, Finish: Grey
Feature:
- 54 modules: 3 x 18 x 18 mm
- 3-row
- per PE/N number x cross section 8 x 25 mm², 32 x 4 mm² Cu, FIXCONNECT® terminal technology, for terminal technology refer to technical data
- N separable, up to 4 different potentials
- for the installation of DIN rail equipment up to 63 A, top hat profile 35 mm
- with transparent door
- for door locking device and sealing device refer to accessories
- with cable entry cover
- with blanking strips for unused DIN rail openings
- degree of protection: IP 65
- colour: grey, RAL 7035
