MTS 1-PHASE CONTROL AND ISOLATION TRANSFORMER
Attribute:
Art.No. 6686371, Single-phase - Control and Isolation Transformers, 250 VA Isolation class T 40/B
Share
Categories : Electronics In the Control Cabinet ,
Brand : MURR
Share
MTS 1-PHASE CONTROL AND ISOLATION TRANSFORMER
Art.No.:6686371, P: 250VA IN: 230/400VAC +/- 15VAC OUT: 230VAC, Single-phase - Control and Isolation Transformers, 250 VA Isolation class T 40/B, Spring clamp terminals
| Art.No. | 6686366 | 6686367 | 6686368 | 6686369 | 6686371 |
| Output rating | 40VA | 63VA | 100VA | 160VA | 250VA |
| Input voltage | 230/400 ±15 V AC | ||||
| Output voltage | OUT: 230VAC | ||||
| Weight | 0.8 kg | 1.15 kg | 2 kg | 2.65 kg | 3.72 kg |
| Dimensions | 79×78×93 | 79×78×93 | 86×84×98 | 101×96×106 | 102×96×108 |
| Fixing centers | 56×56×4.8 | 56×56×4.8 | 64.5×64×4.8 | 86.5×84×4.8 | 86.5×84×4.8 |
Input
| Input voltage | 230/400 ±15 V AC |
|---|---|
| Frequency | 50...60 Hz |
| Input current | 0.24 A (230 V AC); 0.138 A (400 V AC) |
| Inrush current | 1.64 A (230 V AC); 0.94 A (400 V AC) |
| Short-circuit current | 1.88 A (230 V AC); 1.08 A (400 V AC) |
| Standards | EN 61558-1, EN 61558-2-4, EN 62041 category 0 |
|---|---|
| Test isolation voltage | 4 kV (prim./sec.) |
| Mounting method | Long-hole mounting or DIN-rail mountable TH35 (EN 60715) |
| Temperature range | -20...+40 °C (storage temperature -40...+80 °C) |
| Output voltage | 230 V AC |
|---|---|
| Output rating | 40 VA |
