MTS SINGLE-PHASE SAFETY TRANSFORMER
Attribute:
Art.No.:866167..171, Single-phase - Control and Isolation Transformers, 230/400 VAC
Share
Categories : Electronics In the Control Cabinet ,
Brand : MURR
Share
MTS SINGLE-PHASE SAFETY TRANSFORMER P:40-250VA IN:230/400VAC OUT:24VAC
| Art.No. | 866167 | 866168 | 866170 | 866171 |
| Output rating | 40VA | 63VA | 150VA | 250VA |
| Input voltage | 230/400VAC | 230/400VAC | 400VAC±5% | 400VAC±5% |
| Output voltage | 24VAC | 24VAC | 24VAC/230VAC | 24VAC/230VAC |
| Weight | 1.4 kg | 1,8 kg | 2.1 kg | 3.7 kg |
| Dimensions | 87×79×93 | 88×85×98 | 88×84×98 | 104×97×108 |
| FixingCenters | 56×56×4.8 | 64.5×64×4.8 | 64.5×64×4.8 | 86.5×84×4.8 |
Input
| Input voltage | 230/400 V AC |
|---|---|
| Input current | 0.23 A (230 V AC); 0.13 A (400 V AC) |
| Inrush current | 1.4 A (230 V AC); 0.8 A (400 V AC) |
| Short-circuit current | 2.1 A (230 V AC); 1.2 A (400 V AC) |
| Frequency | 50...60 Hz |
| Standards | EN 61558-2-6, EN 62041 category 0 |
|---|---|
| Test isolation voltage | 5.8 kV (prim./sec.) |
| Mounting method | Key-hole mounting |
| Temperature range | -20...+60 °C (storage temperature -40...+80 °C) |
