The IEC 309 HP system comprises plugs and socket-outlets from 16 to 125A in two different versions – straight mobile and 10° flush-mounting.
Share
Categories : Power Plug ,
Brand : GEWISS
Share
Part Nember | GW62026FH |
Colour | Blue |
IP degree | IP66/67/68/69 |
Mechanical resistance | IK09 |
Type | Straight Connector |
Frequency | 50/60 Hz |
Cable clamp tightening capacity | 7.5-13.8 mm |
Type of wiring | Quick, with spring |
Electrocod | 2211 |
Total number of operations | > 5000 |
Breaking capacity at 1.1 Un | 20 A |
Thermo-pressure with ball | 125 °C (active parts) - 80 °C (passive parts) |
Rated current (A) | 16 |
No. of poles | 2P+E |
Reference h | 6 |
Rated voltage | 200 - 250 V |
Terminal tightening capacity | 1-2.5mm² flexible cables - 1.5-4mm² rigid cables |
Operating temperature | -25 +55 °C |
Type of material | Halogen-free in compliance with EN 60754-2 |
Glow wire test | 850 °C (active parts) - 650 °C (passive parts) |
Permissible overload | 22A |
Insulation resistance | > 10 M |
