Industrial & Waterproof series connectors product application are often preferred in Motors, Power, Electronics, Mechanical, Medical Equipment
Share
Categories : Connectors , Circular Connector PLT ,
Brand : PLT
Share
| No. of contacts | 5 | 7 | 8 |
| Contacts Configuration |  |  |  |
| Rated current / Voltage | 5A 125V | 5A 125V | 5A 125V |
| Operation Limit Voltage (AC.V.rms) | 200 | 200 | 200 |
| Withstanding voltage (AC.V.rms) 1 minute | 1000 | 1000 | 1000 |
Insulation resistance (M MIN.) at DC 500V | 1000 | 1000 | 1000 |
| Contact resistance (M MAX.) at DC 1A | 3 | 3 | 3 |
| Solder inter diameter | 1.55 | 1.55 | 1.55 |
| Model Reference | PLT-185-RF-R PLT-185-RFA-R PLT-185-ADF-R PLT-185-PM-R PLT-185A-PF-R PLT-185A-RF-R PLT-185B-RF-R PLT-185A-RM-R PLT-185A-PM-R | PLT-187-RF-R PLT-187-RFA-R PLT-187-ADF-R PLT-187-PM-R PLT-187A-PF-R PLT-187A-RF-R PLT-187B-RF-R PLT-187A-RM-R PLT-187A-PM-R | PLT-188-RF-R PLT-188-RFA-R PLT-188-ADF-R PLT-188-PM-R PLT-188A-PF-R PLT-188A-RF-R PLT-188B-RF-R PLT-188A-RM-R PLT-188A-PM-R |
