PID500, Temperature Controllers - PID Advanced PID Controller
Attribute:
Universal input, 2 relay auxiliary outputs, optional Retransmission and RS485 communication, 90 to 270V AC / DC, 48 x 48 mm, Single step Ramp-Soak function.
Share
Categories : Monitoring & Protection Relay ,
Brand : SELEC
Share
Specifications
| Display Type | 7 Segment LED Dual Display | |
| Display Configuration | 4+4 digits | |
| Type of Inputs | Thermocouple: J, K, T, R, S, C,E, B, N, L, U, W, Platinel II. RTD: PT100, Signal Inputs: (DC) -5 to 56mV, 0 to 10V, 0 to 20mA (Selectable) | |
| Control Output | Relay or SSR or Current : 0/4 to 20mA DC (max load 500E) or Voltage :0 to 5/10V DC(min load 10K) | |
| Auxiliary Output | Relay | |
| Feature | Extra alarm output, Retransmission output | |
| Communication |
| |
| Supply Voltage |
| |
| Size | 48 x 48mm | |
| Mounting Type | Panel Mount | |
| Certification |
|
