VPRD2M-BL, Digital Voltage Protection Relay, Self Powered
Attribute:
Protects from Over / Under Voltage & Frequency, Phase Loss, Asymmetry, Reversal. Suitable for 1P-2W, 3P-4W system, Supply Voltage: 127 to 288V AC
Share
Categories : Monitoring & Protection Relay ,
Brand : SELEC
Share
Specifications
| Measuring Parameter | Under Voltage, Over Voltage, Phase Asymmetry,Phase Failure, Phase Sequence |
| Electrical Connection | 1Ø-2W ,3Ø-4W |
| Display | 3 Digits LCD |
| Time Ranges | Trip Time Delay : 0 to 300sec, Power ON Delay : 0.5 to 300sec, Recovery Time Delay : 0 to 300sec, Response Time : <150ms |
| Accuracy | Trip setting : ±1% ± 2 digits , Time Setting : ±5% of Setting ± 150ms |
| Output Contact | 2 C/O (DPDT ) |
| Output Rating | NO,NC: 5A @ 250V AC /28 V DC |
| Operating Voltage | 127 to 288V AC (L-N) |
| Size | 35 mm |
| Mounting Type | DIN Rail Mount |
| Certification | CE |
