Digital 3 Phase Multifunction Meter : MFM384
Attribute:
3 phase Digital Multifunction meter, 96x96mm Size with %THD measurement up to 31st level, Compatible for 1 phase 2 wire, 2 phase 3 wire, 3 phase 3 wire, 3 phase 4 wire systems, CE, RoHS, UL, MID
Share
Categories : Analog & Digital Meter ,
Brand : SELEC
Share
Specifications
| Display Type | LCD with Backlight, Bargraph Representation |
| Display Configuration | 4 Rows of 4 Digits, 1 Row of 8 Digits |
| Electrical Connection | 3Ø - 3W, 3Ø - 4W, 2Ø - 3W, 1Ø - 2W |
| Type of Output | Pulse Output |
| Features | THD upto 31st Level, Max/Min Demand (Power), Max Demand Current, Phase Sequence Detection |
| Communication Protocol | RS485 and MODBUS RTU |
| CT Primary | 1/5A to 10kA (Programmable for any Value) |
| CT Secondary | 1 / 5A ( Programmable ) |
| PT Primary | 100V to 500kV (Programmable for any Value) |
| PT Secondary | 100V to 500V (Programmable for any Value) |
| Rated Input Current | Nominal 5A AC (Min - 11mA ; Max - 6A) |
| Supply Voltage | 100 to 240V AC (-15% to +12%) |
| Size | 96 x 96mm |
| Mounting Type | Panel Mount |
| Certification | CE, UL Listed |
| Product Code | Supply Voltage | Output | Certification | |
|---|---|---|---|---|
| Pulse Output | Communication (RS485) | |||
| MFM384-C-CE | 100 to 240V AC (-15% to +12%) | Yes | Yes | CE |
| MFM384-C-CU-G | 100 to 240V AC (-15% to +12%) | Yes | Yes | CE, UL |
