KVKE SWITCH FUSES 20-630A
Attribute:
Katko KVKE switch fuses ranging from 200-630A Series, the KVKE series is compact in size. ensuring safe use and a long life expectancy
Share
Categories : Safety Switch ,
Brand : KATKO
Share
Katko KVKE switch fuses ranging from 200-630A Series, the KVKE series is compact in size. The modular structure enables position of drive mechanism to be varied. Connecting silver rivets, have a silver alloy 350 um thickness, ensuring safe use and a long life expectancy.
FEATURE
- 20-32 A:
- 10x38 & BS fuse versions
- DIN rail and screw base mounting as standard
- Available as 3-pole and 4-pole version, 1-pole and 2-pole versions on request
- Handle LK10 and shaft L=180 mm included, suitable for 250 mm deep panel boards
- Fuse covers included
- Black or yellow/red handle, add Y/R to description
- 63-630 A:
- DIN & BS fuse versions
- Four breaking points per phase
- Connecting silver rivets have a silver alloy 350 um thick, thus ensuring a long life expectancy and safe use in demanding conditions
- Compact size saves space
- Modular structure enables position of drive mechanism to be varied, mention when ordering
- Available as 1-, 2-, 3- and 4-pole (200-630 A also 6-pole)
- Black or yellow/red handle (add Y/R to description)
- Auxiliary contacts are easy to install
- Fuse covers included, terminal covers as accessory
- 63-160 A includes handle LK12 and shaft L=220
- 200-630 A includes handle LK14 and shaft LVK=228
