70 RT HP- ISOLATOR- HP-COMMAND- ISOLATING MATERIAL BOX-16A-160A- LOCKABLE BLACK KNOB - IP66
Attribute:
GEWISS Safety Switch, 70 RT HP is a new range of 16A to 160A switch disconnectors in isolating material and metal, supplied in a box. Available in control and emergency
Share
Categories : Safety Switch ,
Brand : GEWISS
Share
70 RT HP is a new range of surface mounted rotary isolators available with plastic or metal boxes, in versions from 16A to 160A, for control (black knob) or emergency (red knob) applications. The range includes distribution board options for front-panel or DIN rail assembly, in 16 to 63A options, all of which can be equipped with auxiliary contacts. The isolators guarantee an innovative IP degree up to IP66/IP67/IP69 and they have been designed to reduce wiring time, simplifying installation, and offer maximum safety and durability.
Applications :
- Air conditioning systems
- Lifts
- Ventilation and vacuum installations
- Industrial kitchens
- Technical rooms
- Industrial automation
| SURFACE-MOUNTING ISOLATOR - CONTROL VERSION WITH LOCKABLE BLACK KNOB - IP66 | |||||
| Code | No. of poles | Outer dim (LxHxD)mm. | Holes entry | Pack Carton | DataSheet |
| Rated current (A): 16 | |||||
| GW 70 401 M | 2P | 140x165x64 | 4 x M20 | 1 | |
| GW 70 402 M | 3P | 140x165x64 | 4 x M20 | 1 | |
| GW 70 402 NM | 3P+N | 140x165x64 | 4 x M20 | 1 | |
| GW 70 403 M | 4P | 140x165x64 | 4 x M20 | 1 | |
| Rated current (A): 25 | |||||
| GW 70 416 M | 2P | 140x165x64 | 2 x M20+ 2 x M25 | 1 | |
| GW 70 417 M | 3P | 140x165x64 | 2 x M20+ 2 x M25 | 1 | |
| GW 70 417 NM | 3P+N | 140x165x64 | 2 x M20+ 2 x M25 | 1 | |
| GW 70 418 M | 4P | 140x165x64 | 2 x M20+ 2 x M25 | 1 | |
| Rated current (A): 32 | |||||
| GW 70 404 M | 2P | 140x165x64 | 2 x M20+ 2 x M25 | 1 | |
| GW 70 405 M | 3P | 140x165x64 | 2 x M20+ 2 x M25 | 1 | |
| GW 70 405 NM | 3P+N | 140x165x64 | 2 x M20+ 2 x M25 | 1 | |
| GW 70 406 M | 4P | 140x165x64 | 2 x M20+ 2 x M25 | 1 | |
| Rated current (A): 40 | |||||
| GW 70 413 M | 2P | 140x165x64 | 2 x M20+ 2 x M25 | 1 | |
| GW 70 414 M | 3P | 140x165x64 | 2 x M20+ 2 x M25 | 1 | |
| GW 70 414 NM | 3P+N | 140x165x64 | 2 x M20+ 2 x M25 | 1 | |
| GW 70 415 M | 4P | 140x165x64 | 2 x M20+ 2 x M25 | 1 | |
| Rated current (A): 63 | |||||
| GW 70 407 M | 3P | 215x252x91 | 4 x M32 | 1 | |
| GW 70 407 NM | 3P+N | 215x252x91 | 4 x M32 | 1 | |
| GW 70 408 M | 4P | 215x252x91 | 4 x M32 | 1 | |
| Rated current (A): 80 | |||||
| GW 70 419 M | 3P | 215x252x91 | 4 x M32 | 1 | |
| GW 70 419 NM | 3P+N | 215x252x91 | 4 x M32 | 1 | |
| GW 70 420 M | 4P | 215x252x91 | 4 x M32 | 1 | |
| Rated current (A): 100 | |||||
| GW 70 421 M | 3P | 307x257x121 | 1 | ||
| GW 70 421 NM | 3P+N | 307x257x121 | 1 | ||
| GW 70 422 M | 4P | 307x257x121 | 1 | ||
| Rated current (A): 125 | |||||
| GW 70 423 M | 3P | 307x257x121 | 1 | ||
| GW 70 423 NM | 3P+N | 307x257x121 | 1 | ||
| GW 70 424 M | 4P | 307x257x121 | 1 | ||
| Rated current (A): 160 | |||||
| GW 70 425 M | 3P | 307x257x121 | 1 | ||
| GW 70 425 NM | 3P+N | 307x257x121 | 1 | ||
| GW 70 426 M | 4P | 307x257x121 | 1 | ||
 | 70 RT HP With a modern and ergonomic design, combined with high impact resistance, UV protection, and protection against chemicals,means this range provides great performance and safety SAFETY 70 RT HP features an improved, ergonomically-designed,robust switch which is ideal for heavy-duty applications. The innovative padlocking system, concealed within the switches,can only be operated using a tool, with space for up to 3 padlocks which can be locked in both ON and OFF positions (in the emergency version the switch can only be locked in the OFF position). VERSATILITY As well as surface-mounted versions, 70 RT HP is also available in a version for distribution boards: either frontpanel installation or DIN rail assembly (EN50022). This means that the range is extremely flexible, as it can be installed in any of GEWISS’ enclosures and distribution boards. |
