TCHI-10 T-Type Bulkhead Mount Housing
Attribute:
ILME Multipole Connector, TCHI-10, T-Type bulkhead mount insulating housing is size 57.27 and features double lever
Share
Categories : Connectors , Multipole Connector คอนเนคเตอร์เหลี่ยม , Hood & Housing-Multipole Connector ,
Brand : ILME
Share
TCHI-10 T-Type
The ILME TCHI-10 T-Type bulkhead mount standard housing is size 57.27 and features a double lever. The body is plastic with thermoplastic levers. Insert center distance: 57 x 27 mm. Rated IP 65. Being plastic, the TCHI-10 is a low cost solution compared to metal housings. It is useful in harsh applications, due to its ability to resist corrosion from chemicals.
| Specifications | |
| Brand | ILME |
| Body | Plastic |
| Gasket | Thermoplastic |
| ILME Series | T |
| Insert Dimension | 57.27 |
| Enclosure Dimension | 57.27 |
| Enclosure Type | 2 Levers |
| Mounting Style | Bulkhead Mount |
| Temperature Range | 40 C to 125 C (-40 F to 257 F) |
| Ingress Protection | IP66 (and IP69 DIN 40050 - 9) |
| Insert Center Distance | 57 x 27 mm. |
| Approvals | C UR US, CCC, GL |
