CC-LINK BUS 1x3xAWG20 Data Cable for signal transmission
Attribute:
สาย CC LInk Cable Network, CC-LINK BUS 1x3xAWG20 Ref. Std. CC-Link Specification 1.10, CM +75°C/+167°F or PLTC
Share
Categories : Industrial Cable ,
Share
CC-LINK BUS 1x3xAWG20
CC LINK BUS : Flame Test: IEC 60332-1, EN 60332-1, VDE 0482-332-1 Halogen-Corrosive Gas Test: IEC 60754-2, EN 50267-2, VDE 0482-267-2 (LSOH için) Smoke Density: IEC 61034-2, EN 61034-2, VDE 0482-1034-2 (LSOH için)
Application : These cables are used for signal transmission in internal building
Construction and Technical data :
Temperature Range : -30 °C- …. +70 °C
Test Voltage : Max. 300 V
Test Voltage : Core/core, core/screen 2000V
Min. Bending Radius : 15xD
THERMAL & MACHANICAL PROPROTIES
Conductor DC Resistance : 37,8
Effective Capacity : 60 nF/Km
Inductance : 0,65 mH/Km
Insulation Resistance: 10 x diameter
CC LINK BUS : Flame Test: IEC 60332-1, EN 60332-1, VDE 0482-332-1 Halogen-Corrosive Gas Test: IEC 60754-2, EN 50267-2, VDE 0482-267-2 (LSOH için) Smoke Density: IEC 61034-2, EN 61034-2, VDE 0482-1034-2 (LSOH için)
Application : These cables are used for signal transmission in internal building
Construction and Technical data :
Temperature Range : -30 °C- …. +70 °C
Test Voltage : Max. 300 V
Test Voltage : Core/core, core/screen 2000V
Min. Bending Radius : 15xD
THERMAL & MACHANICAL PROPROTIES
Conductor DC Resistance : 37,8
Effective Capacity : 60 nF/Km
Inductance : 0,65 mH/Km
Insulation Resistance: 10 x diameter
