EUMAX XC-JN6-R7P JN6 Signal Receptacle 7P, Micro Motor ConnectoR

Name: EUMAX XC-JN6-R7P JN6 Signal Receptacle 7P, Micro Motor ConnectoR
SKU: XC-JN6-R7P EUMAX
Availability: InStock

Attribute:

EUMAX Servo Motor Connector, Gold-plate Copper Alloy, 2 Contacts 5A, 4 Contacts 7A 200VAC ,IP67

Categories : Connectors , Servo Motor Connector ,

XC-JN6-R7P JN6 Signal Receptacle
7P EUMAX Micro Motor ConnectorEUMAX Micro Motor Connector, Servo Motor Connector

Technical Data
Brand	EUMAX
Rated Current	2 Contacts 5A, 4 Contacts 7 A
Rated Voltage	100VAC
Working Temperature	-20 °C - 130 °C
Insulation Resistance	500M Ω /500VDC
Contact Material	Gold-plate Copper Alloy
IP Protection	IP67
Cable O.D.	2 Contacts 4mm-4.8mm, 4 Contacts 6mm-7mm
Wire Cross-Section	0.33-0.75mm,22-18AWG
Application	<750W Motor Signal connector

Servo Mortor Connector EUMAX GM Seriex WaterProof Connector EUMAX Circular Connector EUMAX Industrial Connectors XC-JN6-R7P JN6 Signal Receptacle 7P XC-JN6-R7P JN6 EUMAX XC-JN6-R7P JN6
