LNE-JSB-P4 Double Locked Corrugated PVC Coated Conduit
Attribute:
ท่อเฟล็กซ์ Double Locked Corrugated PVC Coated ท่อเหล็กสังกะสีชุบกัลวาไนซ์ (Hot dip-Galvanized) เคลือบ PVC กันน้ำ ทนอุณหภูมิ -10℃ ~ +80℃, RoHS, CE
Share
Categories : Flexible Conduit ท่อเฟล็กซ์ท่อร้อยสายไฟ , Metal Flexible Conduit ,
Share
LNE-JSB-P4 Double Locked Corrugated PVC Coated Flexible Conduit
Product material：(inner layer) adopting hot-dipped galvanized steel band with special anticorrosion treatment ；(outer layer) adopting PVC raw material (anti-UV, anti-aging)
Working temperature: -10 ~ +80, instantaneously can be +100 , can be customized high temperature and low temperature resistant products
Certification: RoHS,CE,flame retardant certification FV-0
Color：Black,Grey
Property：double-locked galvanized metal Conduit lighter than other products ,having super soft and excellent bending performance,internal smooth structure is very easy for the entry of wire and cable Double locked structure:has strong tensile resistant,high temperature resistant,corrosion resistant
Usage: protecting wires/cables and provide insulation and waterproofing performance.
Application:used in robots,aerospace,power generation,high-speed rail subway,railway equipment,shipbuilding,chemical industry,communication system,engineering equipment installation,industrial automation equipment,machine tool equipment,lighting equipment,electrical insulation protection system of indoor and outdoor environment of wire and cable protection
How to use: Put the wires/cables through conduit before matching the correspondent type of LNE-DPJ connectors.
| NO. | Metric | G System | Outer Diameter | Natural Curve | Max Axial Pull | Packaging Unit |
| LNE-JSB-P4-10 | Φ 10 | 5/16″ | 13.5 ± 0.30 | 55 | 590 | 100 |
| LNE-JSB-P4-13 | Φ 13 | 3/8″ | 16.5 ± 0.35 | 65 | 765 | 100 |
| LNE-JSB-P4-16 | Φ 16 | 1/2″ | 20.0 ± 0.35 | 85 | 940 | 100 |
| LNE-JSB-P4-20 | Φ 20 | 3/4″ | 24.3 ± 0.40 | 100 | 1180 | 50 |
| LNE-JSB-P4-25 | Φ 25 | 1″ | 30.3 ± 0.45 | 120 | 1450 | 50 |
| LNE-JSB-P4-32 | Φ 32 | 1 1/4″ | 38.0 ± 0.50 | 150 | 1885 | 25 |
| LNE-JSB-P4-38 | Φ 38 | 1 1/2″ | 45.0 ± 0.60 | 180 | 2240 | 25 |
| LNE-JSB-P4-51 | Φ 51 | 2″ | 58.0 ± 1.00 | 220 | 3000 | 20 |
