BC-AL-050503 BOXCO Alumminum Enclosure Box
Attribute:
กล่องอลูมิเนียมกันน้ำ Boxco IP66/67, Screw type, RAL7001 แข็งแรงทนทานไม่เป็นสนิม ทนอุณหภูมิสูง ขนาด (46×51×32 mm)
Share
Categories : Enclosure Boxes - Cabinet , Aluminium Enclosure Box ,
Brand : BOXCO
Share
Aluminium Enclosures กล่องอลูมิเนียมกันน้ำ
ทนทานต่อสารเคมีได้ดีเยี่ยม เป็นตู้ปิดผนึกและสามารถใช้งานได้ในช่วงอุณหภูมิกว้าง เหมาะสมที่จะใช้สำหรับพื้นที่ในร่ม กลางแจ้ง หรือชายฝั่งในสภาพแวดล้อมที่เป็นอันตรายซึ่งคาดว่าจะสัมผัสกับน้ำทะเล
FEATURE :
1. BOXCO's diecast aluminum enclosures have excellent resistance against chemicals.
2. It is sealed enclosure with Type 4X rating and can be used in wide temperature range.
3. BOXCO IP67 rated waterproof enclosures are proper to be used for indoor, outdoor or coastal area in harmful environment where expected to be contact with sea water.
| Product model | Mounting plate | |||||
| Model | Outside dimension | Inside dimension | Steel | Size(mm) | ||
| size (W1xL1xH1/mm) | Cover (H3) | Base (H4) | Size (W2xL2xH2/mm) | |||
| BC-AL-050503 | 45X50X32 | 7 | 25 | 46X41X26.5 | - | - |
| BC-AL-060603 | 64X58X34 | 9 | 25 | 58X52X28.5 | - | - |
| BC-AL-060605 | 64X58X46 | 9 | 37 | 58X52X40.5 | - | - |
| BC-AL-061003 | 64X98X34 | 9 | 25 | 92X58X28.5 | - | - |
| BC-AL-061005 | 64X98X46 | 9 | 37 | 92X58X40.5 | - | - |
| BC-AL-061503 | 64X150X34 | 9 | 25 | 144X58X28.5 | - | - |
| BC-AL-061505 | 64X150X46 | 9 | 37 | 144X58X40.5 | - | - |
| BC-AL-080806 | 80X75X57 | 15 | 42 | 72X67X49 | 0808A | 69X64 |
| BC-AL-080807 | 80X75X70 | 15 | 55 | 72X67X62 | 0808A | 69X64 |
| BC-AL-081306 | 80X125X57 | 15 | 42 | 117X72X50 | 0813A | 114X69 |
| BC-AL-081307 | 80X125X70 | 15 | 55 | 117X72X63 | 0813A | 114X69 |
| BC-AL-081806 | 80X175X57 | 15 | 42 | 167X72X50.5 | 0818A | 164X69 |
| BC-AL-081807 | 80X175X70 | 15 | 55 | 167X72X63 | 0818A | 164X69 |
| BC-AL-082506 | 80X250X57 | 15 | 42 | 240X70X50 | 0825A | 239X69 |
| BC-AL-082507 | 80X250X70 | 15 | 55 | 240X70X63 | 0825A | 239X69 |
| BC-AL-101008 | 100X100X81 | 20 | 61 | 91X91X74 | 1010A | 88X88 |
| BC-AL-101608 | 100X160X81 | 20 | 61 | 151X91X74 | 1016A | 148X88.5 |
| BC-AL-121208 | 120X122X81 | 20 | 61 | 113X117X74 | 1212A | 109X107 |
| BC-AL-122208 | 120X220X81 | 20 | 61 | 211X111X74 | 1222A | 208X107 |
| BC-AL-122209 | 120X220X91 | 30 | 61 | 211X111X82 | 1222A | 208X107 |
| BC-AL-123608 | 120X360X81 | 20 | 61 | 351X111X72 | 1236A | 347X107 |
| BC-AL-151309 | 150X130X90 | 20 | 71 | 141X123X82 | 1513A | 135X118 |
| BC-AL-161609 | 160X160X91 | 20 | 71 | 151X151X82 | 1616A | 145X144 |
| BC-AL-162110 | 160X210X100 | 20 | 80 | 200X150X92 | 1621A | 193X143 |
| BC-AL-162609 | 160X260X91 | 20 | 71 | 251X151X82 | 1626A | 243X143 |
| BC-AL-163609 | 160X360X91 | 20 | 71 | 349X149X23 | 1630A | 343X143 |
| BC-AL-181810 | 180X180X101 | 30 | 71 | 171X171X192 | 1818A | 167X167 |
| BC-AL-232011 | 230X200X111 | 20 | 91 | 220X190X102 | 2320A | 213X184 |
| BC-AL-232018 | 230X200X180 | 20 | 160 | 222X192X167 | 2320A | 213X184 |
| BC-AL-232811 | 230X280X111 | 20 | 91 | 270X220X102 | 2328A | 265X213 |
| BC-AL-233311 | 230X330X111 | 20 | 91 | 320X220X102 | 2333A | 314X213 |
| BC-AL-314011 | 313X404X111 | 20 | 91 | 394X303X102 | 3140A | 385X292 |
| BC-AL-314018 | 313X404X181 | 20 | 161 | 394X303X167 | 3140A | 385X292 |
