Art.No.10415 Current: 10 A DIN-rail mountable for universal applications Attenuation curves on request. Weight:0.312 kg
Share
Categories : Electronics In the Control Cabinet ,
Brand : MURR
Share
MEF EMC-FILTER 1-PHASE 1-STAGE I:10A U:250 VAC/300 VDC snap on
Art.No.: 10415
Weight: 0.312 kg
DESCRIPTION
| Operating voltage | max. 250 V AC/300 V DC |
|---|---|
| Operating frequency | 50...60 Hz |
| Consumption | max. 5 mA (250 V AC) |
| Overload current | 18 × (IN t) max. 0.5 ms; 1.5 × (IN t) max. 1 min. (1 × per hour) |
| Connection cross section | 0.2...6 mm² single core (AWG 24...9); 0.2...4 mm² multiple core (AWG 24...11) |
| Climatic category | 25/085/21 (EN 60068-1) |
|---|---|
| Test isolation voltage | 2.7 kV (L - N), 2 s; 2.1 kV (L - L), 2 s (EN 60939-2) |
| Connection | Screw connection, touch protected |
| Mounting method | DIN-rail mountable TH35 (EN 60715) |
| Dimensions H × W × D | 107×65×39 mm |
